alloy steel seamless tube
"
Tubo senza cuciture dell'acciaio legato del titanio GB/T3625 del condensatore
Round Seamless Titanium Pipe Alloy Steel Pipe For Heater Exchanger Round Seamless Titanium Pipe Alloy Steel Pipe For Heater Exchanger Standard: GB/T3624, GB/T3625, ASTM B338/ASME SB338, ASTM B861/ASME SB861, DIN17861 Size range: OD: 10-80mm WT: 0.5-4.5mm Length: 15m max Material: TA1, TA2, TA3, TA9, TA10 Usage: Condenser and Heater-Exchangers Chemical Composition% Grade N max C max H max Fe max O max Residual Al V Pd Mo Cr Si max S max Mn max Cu Oth ers Ni Ti Each max Total
JIS G3475 STKN400 Tubi senza cuciture in acciaio al carbonio Tubi a parete spessa per strutture edilizie
JIS G3475 STKN400 STKN490 Carbon Steel Seamless Tubes: Thick Wall Steel Pipe for Building Structure Material JIS G3475 specifies the requirements for carbon steel seamless tubes used in various structural applications. The STKN400 and STKN490 grades are particularly designed for precision applications, providing excellent mechanical properties and weldability. Specification The seamless tubes under JIS G3475 are characterized by their high strength and durability, making them
143 - 187 metropolitana dell'acciaio legato delle BS 970 dell'HB 805H20 trafilata a freddo con normalizzato/estiguuta
BS970 805H20 Alloy Steel Tube BS970 Alloy Steel Grade Alloy steels can be supplied with a grain size of 5 to 8 determined in accordance with BS4490 or another method by agreement. Steel supplied to hardenability reqquirements are supplied fine-grained and if coarse grain steel is specifically required, then the hardenaility shall be subject to negotiation. 251A58 251H60 251A60 525H60 525A58 685H57 525A60 704H60 525A61 705H60 685A57 735H51 704A60 805H60 705A60 735A51 735A54
certificato del protettore ISO9001 TS16949 dell'estremità della pianura del tubo dell'acciaio legato di alta precisione
ASTM A209 T1 T1a T1b Seamless Alloy Steel Tubes For Boiler and Superheater Size range: O.D.: 6-420mm W.T.:1-50mm L: according to customer requirement Steel Grade and Chemical Compositions: Element T1 T1a T1b Carbon 0.10-0.20 0.15-0.25 0.14max Manganese 0.30-0.80 0.30-0.80 0.30-0.80 Phosphorus 0.025 0.025 0.025 Sulfur max 0.025 0.025 0.025 Silicon 0.10-0.50 0.10-0.50 0.10-0.50 Molybdenum 0.44-0.65 0.44-0.65 0.44-0.65 Mechanical Properties: Element T1 T1a T1b Tensile strength
Tubi senza saldatura in acciaio al carbonio ASTM A334 Gr6 con prestazioni a bassa temperatura e precisione trafilata a freddo
ASTM A334 Grade 6 Carbon Steel Seamless Tubes Material Description ASTM A334 Grade 6 carbon steel seamless tubes are engineered low-temperature service pipes manufactured from medium carbon steel with controlled chemistry and mechanical properties to ensure reliability in sub-zero environments. They are available as seamless and welded tubes designed for pressure, fluid, and structural duties where high toughness and impact resistance at low temperatures are essential.
tubo dell'acciaio legato di 16MnCr6 20MnCr5 20CrMn, metropolitana di acciaio senza cuciture trafilata a freddo TS16949
Alloy Steel Tubes and Pipes 16MnCr5 20MnCr5 20CrMn Alloy steel grade 20MnCr5 equivalent to 20CrMn Steel Tubes with alloy steel grade 20MnCr5: 16MnCr5 C:0.14-0.19, Mn:1.00-1.30, P≤0.035, S≤0.010-0.050, Cr:0.80-1.10, Si≤0.40 20MnCr5 C:0.17-0.22, Mn:1.10-1.50, P≤0.035, S≤0.10-0.050, Cr:1.00-1.30, Si≤0.25 20CrMn C:0.17-0.23, Mn: 0.90-1.20, Cr:1.00-1.30, Si:0.17-0.37 Mechanical Properties: Tensile strength: min 885Mpa Yield strength: min 685Mpa Elongation: min 12% Hardness: max
tubo trafilato a freddo dell'acciaio legato 20CrNiMo per gli ST di iso degli alberi a gomito degli ingranaggi standard
Products Description: used for Gears Crankshafts Chinese Grade 20CrNiMo Cold Drawn Seamless Alloy Steel Tubes Quick Detail: Chemical Compositions: Steel Grade C Si Mn Cr Ni Mo P S Ti 20CrNiMo 0.17-0.23 0.17-0.37 0.60-0.95 0.40-0.70 0.35-0.75 0.20-0.30 ≤0.035 ≤0.035 - AISI8620 0.18-0.23 0.15-0.35 0.70-0.90 0.40-0.60 0.40-0.70 0.15-0.25 ≤0.035 ≤0.040 - AISI8620H 0.17-0.23 0.15-0.35 0.60-0.95 0.35-0.65 0.35-0.75 0.15-0.25 - - - 20CrMnTiH 0.17-0.23 0.17-0.37 0.80-1.15 1.00-1.35 -
I tubi lavorati freddi meccanici dell'acciaio legato hanno temprato AISI4130 AISI4140
Alloy steel 4130 4140 for ASTM A519 seamless steel tubes ASTM A519 SEAMLESS STEEL TUBES, by DOM production, with the steel grade of SAE4140 and SAE4130, other alloy steel grade upon customer's agreement.: SAE4130: C: 0.28-0.33% Mn: 0.40-0.60% P max 0.40% S max 0.40% Si: 0.15-0.35% Cr: 0.80-1.10% Mo: 0.15-0.25% SAE4140: C: 0.38-0.43% Mn: 0.75-1.00% P max 0.40% S max 0.40% Si: 0.15-0.35% Cr: 0.80-1.10% Mo: 0.15-0.25% Sizing Method: 1. HF- hot finished 2.CW-cold worked Themal
Inconel tubatura senza cuciture e saldata di 600 del nichel dell'acciaio legato dell'acqua
Inconel 600 Seamless and welded Nickel Alloy Steel Tube water tubing Type: Nickel alloy steel pipes Application: For Barge and tank truck liners, Carburizing atmospheres, Ethylene dichloride crackers Technique: Cold-finished, hot-finished Size: OD 5-420mm WT 0.5-50mm LENGTH max12000mm Product Description Chemical Composition: Item 600 601 617 625 690 718 X750 825 C ≤0.15 ≤0.1 0.05-0.15 ≤0.08 ≤0.05 ≤0.08 ≤0.08 ≤0.05 Mn ≤1 ≤1.5 ≤0.5 ≤0.35 ≤0.5 ≤0.35 ≤1 ≤1 Fe 6-10 rest ≤3 rest 7
